norm |
8T |
|
|
Maximum operating radius |
18m |
|
|
Maximum above ground lift |
21m |
|
|
winches
|
Hook Rising Speed |
12m/min (4 ropes) Two-speed |
|
Wire Rope Specifications |
|
|
|
Telescopic
|
Boom form |
5m x 5-section lifting arm (customizable) |
|
Boom length/time |
5.5m-21m/54sec(adjustable) |
|
|
luffing device |
Boom angle/time |
0-78°/13sec |
|
cyclotron |
Rotation angle/speed |
0-360° (continuous)/38sec |
|
Outrigger
|
Forms of outrigger movement |
Manual screw out + cylinder support |
|
Maximum extension amplitude (mm) |
7000 (length) X5070 (rear) X6700 (front) |
|
|
Vehicle Size |
Length 6.15 m, Width 1.6 m, Height 2.25 m |
|
|
Running Gear
|
Walking mode |
hydraulic drive |
|
Walking speed |
0-2.5km/h |
|
|
Gradeability |
25°(36%) |
|
|
Track |
350(width) 52.5 (pitch) 104 (section) |
|
|
Engine
|
Manufacturer |
Yunai (customizable) 58kw |
|
Start mode |
electric start |
|
|
Start performance |
-50°C-45°C |
|
|
Fuel/Volume |
Diesel/35L |
|
|
Battery capacity |
24v 45AH |
|
|
model number |
490CC |
|
|
Operating
|
Type of operation (boom/outrigger), manual traveling |
Manual operation, manual travel (optional remote control operation) |
|
Operational |
Manual operation (remote operation optional) |
|
|
Emission Standard |
National‑II Emission Standard |
|
|
Self-weight (T) |
8.7T |
|
|
Optional |
Optional torque controller/remote control/cradle/hydraulic flying jib/colors: red, green, yellow, white, grey, black |
|
